HX711 AD-Modul, Gewichtssensor, 1 kg, 2 kg, 3 kg, 5 kg, 10 kg, 100 g, Wägezellenmodul, Wägedrucksensor, Messwerkzeuge
ab CHF 7.90
💬 076 792 63 50 (WhatsApp / SMS)
🇩🇪 Deutsch
HX711 AD Module Weight Sensor 1kg 2kg 3kg 5kg 10kg 100g Load Cell Module Weighing Pressure Sensor Measurement Tools Technical Parameters: Range: 1-10kg Output sensitivity: 1.0±0.1mV/V Zero output: ±0.1mV/V Nonlinear: 0.05% F.S Lag: 0.05% F.S Repeatability: 0.05% F.S Creep: 0.05% F.S/3min Output impedance: 1000±5% ohms Zero temperature drift: 0.05% F.S/10°C Temperature sensitivity drift: 0.05% F.S/10°C Lead Cable: Motivation is positive: red Incentive negative: green Signal is positive: black signal Negative : white Package included: 1 × Weighing Pressure Sensor
